Material:
Die casting body.
Gear box available.
Tempered glass cover and PC lens.
|
Product Code |
YAHP-20-31-1P | YAHP-20-31-2P | YAHP-20-31-3P | |||
| Input Wattage | 500-600W | 1000-1200W | 1500-1800W | |||
| Number of lenses | 48 | 96 | 144 | |||
| LED Quantity 5050 PCS | 288/384 | 576/768 | 864/1152 | |||
| Product Size（mm） | 423X763X191 | 630X883X197 | 925X883X197 | |||
| Packing Size（mm） | 470X810X230 | 690X940X250 | 980X940X250 | |||
| Net Weight | 18.2 kgs | 37.8 kgs | 53.9 kgs | |||
| Gross Weight | 20.2 kgs | 41.8 kgs | 60.0 kgs | |||
| Quantity of packing | 1 PCS | 1 PCS | 1 PCS | |||
| Installation Height | 20～30m | 30～40m | 40～50m | |||
| Materials | Housing:ADC12;Cover:Toughened Glass；Screws:304stainless screws | |||||
| Spray colors | Two-tone grey Black fine sand Flash silver sand | |||||
| Led brand | LUMILEDS，OSRAM，CREE(Optional) | |||||
| Optical effect | 150/170 lm/w(Optional) | |||||
| Color Temperature | 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference：Energy Star) | |||||
| color rendering index | Ra≥70；Ra≥80；Ra≥90(Optional) | |||||
| Optics | 15°25°45°60°90°90*120°TYPE I,TYPE II,TYPE III,TYPE V,TYPE IV(Optional) | |||||
| Driver brand | PHILIPS / OSRAM / TRIDONIC / MEAN WELL / SOSEN / INVENTRONICS | |||||
| Input Voltage | AC90～305V | |||||
| Security level | ClassI/ClassII/Class1/Class2(Optional) | |||||
| Frequency Range | 50/60Hz | |||||
| Power Factor | PF≥0.95 | |||||
| Protection | Overcurrent/Short circuit/Over temperature | |||||
| Dimming mode | Time control/0-10V/ Opticalcontrol/Microwaves/DALI(Optional) | |||||
| Lightning protection | 10KV/15KV/20KV(Optional) | |||||
| Working conditions Range | -30 to 45℃,20% to 90%RH | |||||
| Warranty | 5/8 year(Optional) | |||||
| Protection level | IP66;IK09。 | |||||
| Certifications | CE;RoHs;LM-80;IP66 | |||||
| YAHP-20 | IES Type Light distribution curve | |||||||
| GD-30 | GD-60 | GD-90 | GX-50 | GJ-P45 | GJ-90 | |||
| GH-25 | GH-45 | GH-60 | GH-90 | GH-120 | ||||
| HH-15 | HH-25 | HH-45 | HH-60 | HH-90 | HH-90*120 | |||
