Material:
Die casting body.
Gear box available.
Tempered glass cover and PC lens.
| YAHP-13 Product parameters | |||||||||
| Product Code | YAHP-13-800 | YAHP-13-1200 | YAHP-13-1600 | ||||||
| Input Wattage(W) | 500-800 | 800-1000 | 1200-1500 | ||||||
| Number of lenses(pcs) | 4 | 4 | 4 | ||||||
| Product Size（mm） | 504x507x177 | 577x600x184 | 675x661x196 | ||||||
| Packing Size（mm） | 550x550x240 | 680x640x240 | 730x730x260 | ||||||
| Net Weight | 19 | 28 | 42 | ||||||
| Gross Weight | 20.5 | 30 | 44.5 | ||||||
| Quantity of packing (pcs) | 1 | 1 | 1 | ||||||
| 材料Materials | Housing:ADC12;Cover:Toughened Galss；Screws:304stainless screws | ||||||||
| 喷塑颜色Spray colors | Double Grey, Sandy Black | ||||||||
| Led brand | PHILIPS / OSRAM / CREE (Optional) | ||||||||
| LED | 5050 | ||||||||
| LED | 360 | 480 | 720 | ||||||
| Optical effect | 130-170lm/W | ||||||||
| Color Temperature | 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference：Energy Star) | ||||||||
| Color rendering index | Ra≥70；Ra≥80；Ra≥90(Optional) | ||||||||
| Optics | 20°/40°/60° | ||||||||
| Driver brand | PHILIPS / OSRAM / TRIDONIC / MEAN WELL / SOSEN / INVENTRONICS | ||||||||
| Input Voltage | AC200-240V | ||||||||
| Security level | ClassI | ||||||||
| Frequency Range | 50/60Hz | ||||||||
| Power Factor | PF≥0.95 | ||||||||
| Protection | Overcurrent/Short circuit/Over temperature | ||||||||
| Dimming mode | Time control/0-10V/Microwaves(Optional) | ||||||||
| Lightning protection | 10KV/15KV/20KV(Optional) | ||||||||
| Working conditions Range | -40 to 45℃,20% to 90%RH | ||||||||
| Warranty | 5 year | ||||||||
| Protection level | IP65;IK08 | ||||||||
| Certifications | CE;RoHs；Lighting protection;LM-79;LM-80;IP66 | ||||||||
